Downloaded over 5 Billion times, NumPy is the most popular library for numerical computing in Python.
It wraps low-level HPC libraries like BLAS and LAPACK, providing a high-level interface for matrix operations.
BLAS is mainly implemented in C, Fortran, or Assembly and is available for most modern chips, not just CPUs.
BLAS is fast, but bindings aren’t generally free.
So, how much of the BLAS performance is NumPy leaving on the table?
TLDR: up to 90% of throughput is lost on 1536-dimensional OpenAI Ada embeddings, more on shorter vectors.
SimSIMD can fix that, at least partly.
We aren’t going to cover the basics of NumPy or BLAS.
We won’t cover BLAS level 2 or 3 for vector-matrix and matrix-matrix operations, only level 1 vector-vector dot-products.
We have already shown how pure Assembly dot-products can be over 2,000x faster than Python.
We have also demonstrated how bindings across 10 programming languages work.
Instead, let’s jump into benchmark results.
Baseline Benchmarks#
I wrote 2 benchmark scripts: one in Python and one in C++ using Google Benchmark.
In short, we are benchmarking the following interfaces against their BLAS counterparts:
1
2
3
4
5
6
7
8
9
| import numpy as np
a = np.random.rand(1536)
b = np.random.rand(1536)
np.dot(a.astype(np.float64), b.astype(np.float64)) # cblas_ddot
np.dot(a.astype(np.float32), b.astype(np.float32)) # cblas_sdot
np.dot(a.astype(np.float16), b.astype(np.float16)) # no analog
np.dot(a.astype(np.float64).view(np.complex128), b.astype(np.float64).view(np.complex128)) # cblas_zdotu_sub
np.dot(a.astype(np.float32).view(np.complex64), b.astype(np.float32).view(np.complex64)) # cblas_cdotu_sub
|
They directly compare NumPy’s default PyPi distribution with the same underlying OpenBLAS library used from the C layer.
For profiling, I chose the c7g instances on AWS, powered by Arm-based Graviton 3 CPUs with Scalable Vector Extensions (SVE) - variable-width SIMD Assembly instructions - my favorite example of convergence between CPUs and GPUs.
AWS Graviton 3 CPUs are an excellent baseline for the new wave of energy-efficient supercomputers and clouds.
Arm also powers Fugaku, the fastest supercomputer until 2022, which also supports SVE.
Nvidia Grace CPUs are also based on Arm, Neoverse N2 cores to be precise.
They also support SVE instructions and already power Isambard 3 supercomputer in Bristol, one of the greenest in the world.
Similarly, Microsoft Azure is rolling out its Cobalt CPUs, and the Ampere One is gaining adoption.
| Numeric Type | OpenBLAS in C | OpenBLAS in NumPy | Slowdown |
|---|
float64 ¹⁵³⁶ | 1,693 K | 479 K | 3.53 x |
float32 ¹⁵³⁶ | 6,568 K | 752 K | 8.73 x |
float16 ¹⁵³⁶ | _ | 173 K | - |
complex128 ⁷⁶⁸ | 1,706 K | 469 K | 3.64 x |
complex64 ⁷⁶⁸ | 2,980 K | 632 K | 4.71 x |
complex32 ⁷⁶⁸ | - | - | - |
The benchmarks were run on a single thread, resulting in dot-product operations per second.
In this case, NumPy is 3.53x to 8.73x slower than the underlying BLAS library for 1536-dimensional real and 768-dimensional complex vectors.
The smaller you make the vectors, the more significant the slowdown.
The slowdown comes from multiple sources:
- Dynamic dispatch - as Python is a dynamic language, locating the dot symbol may involve several lookup tables and function calls,
- Type checking - as Python is a dynamically typed language, the native implementation of dot must check the argument types, check if they are compatible,
- Memory allocations - NumPy has to allocate memory for the result and then free it.
We can partly mitigate that.
SimSIMD#
In the v4 release of SimSIMD, I’ve added complex dot products.
SimSIMD now also supports half-precision complex numbers, not supported by NumPy or most BLAS implementations, but considered for CuPy.
Looking at hardware-accelerated dot-products specifically, this is how SimSIMD and NumPy compare in terms of functionality:
| NumPy | SimSIMD |
|---|
| Real Types | float16, float32, float64 | float16, float32, float64 |
| Complex Types | complex64, complex128 | complex32, complex64, complex128 |
| Backends | Come from BLAS | NEON, SVE, Haswell, Skylake, Ice Lake, Sapphire Rapids |
| Compatibility | 35 wheels on PyPi | 105 wheels on PyPi |
The library also contains benchmarks against OpenBLAS, which I’ve used in this article.
First, I’ve profiled the C layer, looking for ways to supersede OpenBLAS and comparing auto-vectorization with explicit SIMD kernels.
| Numeric Type | OpenBLAS in C | Serial C Code | SimSIMD in C | Improvement |
|---|
float64 ¹⁵³⁶ | 1,693 K | 861 K | 2,944 K | + 73.9 % |
float32 ¹⁵³⁶ | 6,568 K | 1,248 K | 5,464 K | - 16.8 % |
float16 ¹⁵³⁶ | _ | 845 K | 10,500 K | |
complex128 ⁷⁶⁸ | 1,706 K | 1.264 K | 2,061 K | + 20.8 % |
complex64 ⁷⁶⁸ | 2,980 K | 1,335 K | 3,960 K | + 32.9 % |
complex32 ⁷⁶⁸ | - | 881 K | 7,138 K | |
The comparison wasn’t possible for half-precision representations.
In the remaining 4 cases, SimSIMD won 3 times and lost once.
Patches for the lost case are more than welcome 🤗
Putting all together, this is how SimSIMD and NumPy compare when used in Python:
| Numeric Type | NumPy in Python | SimSIMD in Python | Improvement |
|---|
float64 ¹⁵³⁶ | 479 K | 753 K | + 57.2 % |
float32 ¹⁵³⁶ | 752 K | 1,215 K | + 61.6 % |
float16 ¹⁵³⁶ | 173 K | 1,484 K | + 757.8 % |
complex128 ⁷⁶⁸ | 469 K | 737 K | + 57.1 % |
complex64 ⁷⁶⁸ | 632 K | 1,011 K | + 60.0 % |
complex32 ⁷⁶⁸ | - | 1,173 K | |
In all cases but one, the SimSIMD improvements over NumPy can be attributed to the quality of the binding layer, the BLAS wasn’t the bottleneck.
NumPy could have been just as fast as SimSIMD, if it had a better binding layer.
In half-precision, however, the NumPy doesn’t call BLAS, and as a result, it’s 8x slower than SimSIMD.
Assuming how often numpy.inner, numpy.dot, and numpy.vdot are used, I’ll call this a win.
So if you want to make your pipelines - pip install simsimd 😉
Replicating the Results#
1
2
3
4
5
6
7
8
9
10
11
12
13
| # Clone the repos and install BLAS
$ sudo apt install libopenblas-dev
$ git clone https://github.com/ashvardanian/SimSIMD.git
$ cd SimSIMD
# To run C benchmarks for dot products
$ cmake -DCMAKE_BUILD_TYPE=Release -DSIMSIMD_BUILD_BENCHMARKS=1 -B build_release
$ cmake --build build_release --config Release
$ build_release/simsimd_bench --benchmark_filter="dot.*(serial|blas|sve)"
# To run Python benchmarks
$ pip install numpy scipy scikit-learn
$ python python/bench.py
|
Appending 1: C++ Benchmark Logs#
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
| - Arm NEON support enabled: true
- Arm SVE support enabled: true
- x86 Haswell support enabled: false
- x86 Skylake support enabled: false
- x86 Ice Lake support enabled: false
- x86 Sapphire Rapids support enabled: false
- Compiler supports F16: true
- Benchmark against CBLAS: true
2024-03-13T05:58:15+00:00
Running build_release/simsimd_bench
Run on (4 X 2100 MHz CPU s)
CPU Caches:
L1 Data 64 KiB (x4)
L1 Instruction 64 KiB (x4)
L2 Unified 1024 KiB (x4)
L3 Unified 32768 KiB (x1)
Load Average: 0.12, 0.23, 0.31
***WARNING*** Library was built as DEBUG. Timings may be affected.
----------------------------------------------------------------------------------------------------------
Benchmark Time CPU Iterations UserCounters...
----------------------------------------------------------------------------------------------------------
dot_f32_blas_1536d/min_time:10.000/threads:4 38.2 ns 152 ns 91962500 abs_delta=0 bytes=80.7067G/s pairs=6.56793M/s relative_error=0
dot_f64_blas_1536d/min_time:10.000/threads:4 149 ns 590 ns 23714404 abs_delta=0 bytes=41.6305G/s pairs=1.69395M/s relative_error=0
dot_f32c_blas_1536d/min_time:10.000/threads:4 84.0 ns 336 ns 41723636 abs_delta=0 bytes=36.6258G/s pairs=2.98061M/s relative_error=0
dot_f64c_blas_1536d/min_time:10.000/threads:4 147 ns 586 ns 23884736 abs_delta=0 bytes=41.9479G/s pairs=1.70687M/s relative_error=0
vdot_f32c_blas_1536d/min_time:10.000/threads:4 84.1 ns 336 ns 41718708 abs_delta=0 bytes=36.6236G/s pairs=2.98043M/s relative_error=0
vdot_f64c_blas_1536d/min_time:10.000/threads:4 147 ns 586 ns 23895620 abs_delta=0 bytes=41.9427G/s pairs=1.70665M/s relative_error=0
dot_f16_sve_1536d/min_time:10.000/threads:4 23.9 ns 95.2 ns 146982384 abs_delta=119.209u bytes=64.5152G/s pairs=10.5005M/s relative_error=158.405u
dot_f32_sve_1536d/min_time:10.000/threads:4 45.9 ns 183 ns 76501512 abs_delta=0 bytes=67.1458G/s pairs=5.46434M/s relative_error=0
dot_f64_sve_1536d/min_time:10.000/threads:4 85.0 ns 340 ns 41207148 abs_delta=0 bytes=72.3747G/s pairs=2.94493M/s relative_error=0
dot_f16c_sve_1536d/min_time:10.000/threads:4 35.1 ns 140 ns 99915388 abs_delta=817.418u bytes=43.8583G/s pairs=7.1384M/s relative_error=1094.91u
vdot_f16c_sve_1536d/min_time:10.000/threads:4 35.1 ns 140 ns 99876424 abs_delta=446.2u bytes=43.915G/s pairs=7.14763M/s relative_error=609.749u
dot_f32c_sve_1536d/min_time:10.000/threads:4 63.2 ns 253 ns 55436532 abs_delta=0 bytes=48.6621G/s pairs=3.96013M/s relative_error=0
vdot_f32c_sve_1536d/min_time:10.000/threads:4 63.1 ns 252 ns 55614928 abs_delta=0 bytes=48.8208G/s pairs=3.97305M/s relative_error=0
dot_f64c_sve_1536d/min_time:10.000/threads:4 122 ns 485 ns 28866668 abs_delta=0 bytes=50.6679G/s pairs=2.06168M/s relative_error=0
vdot_f64c_sve_1536d/min_time:10.000/threads:4 122 ns 485 ns 28876568 abs_delta=0 bytes=50.686G/s pairs=2.06242M/s relative_error=0
dot_f16_serial_1536d/min_time:10.000/threads:4 297 ns 1183 ns 11832888 abs_delta=0 bytes=5.19258G/s pairs=845.147k/s relative_error=0
dot_f32_serial_1536d/min_time:10.000/threads:4 201 ns 801 ns 17471224 abs_delta=0 bytes=15.3362G/s pairs=1.24806M/s relative_error=0
dot_f64_serial_1536d/min_time:10.000/threads:4 291 ns 1161 ns 12059628 abs_delta=0 bytes=21.1718G/s pairs=861.482k/s relative_error=0
dot_f64c_serial_1536d/min_time:10.000/threads:4 198 ns 791 ns 17704468 abs_delta=0 bytes=31.0815G/s pairs=1.26471M/s relative_error=0
dot_f32c_serial_1536d/min_time:10.000/threads:4 187 ns 749 ns 18696188 abs_delta=0 bytes=16.4102G/s pairs=1.33546M/s relative_error=0
dot_f16c_serial_1536d/min_time:10.000/threads:4 284 ns 1135 ns 12337624 abs_delta=0 bytes=5.41538G/s pairs=881.409k/s relative_error=0
|
Appending 2: Python Benchmark Logs#
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
| - Vector dimensions: 1536
- Vectors count: 1000
- Hardware capabilities: serial, neon, sve
- SimSIMD version: 4.0.0
- SciPy version: 1.11.3
- scikit-learn version: 1.4.1.post1
- NumPy version: 1.26.0
-- NumPy BLAS dependency: openblas64
-- NumPy LAPACK dependency: openblas64
| Datatype | Method | Ops/s | SimSIMD Ops/s | SimSIMD Improvement |
| :------- | :-------------------- | ------: | ------------: | ------------------: |
| `f64` | `scipy.cosine` | 40,362 | 690,516 | 17.11 x |
| `f32` | `scipy.cosine` | 31,097 | 1,138,570 | 36.61 x |
| `f16` | `scipy.cosine` | 14,631 | 1,393,120 | 95.21 x |
| `i8` | `scipy.cosine` | 39,489 | 1,473,040 | 37.30 x |
| `f64` | `scipy.sqeuclidean` | 154,574 | 718,487 | 4.65 x |
| `f32` | `scipy.sqeuclidean` | 176,013 | 1,180,098 | 6.70 x |
| `f16` | `scipy.sqeuclidean` | 47,537 | 1,411,140 | 29.69 x |
| `i8` | `scipy.sqeuclidean` | 121,854 | 1,416,866 | 11.63 x |
| `f64` | `numpy.dot` | 478,866 | 752,517 | 1.57 x |
| `f32` | `numpy.dot` | 752,299 | 1,214,928 | 1.61 x |
| `f16` | `numpy.dot` | 172,994 | 1,484,285 | 8.58 x |
| `i8` | `numpy.dot` | 511,496 | 1,571,563 | 3.07 x |
| `f32c` | `numpy.dot` | 631,648 | 1,010,783 | 1.60 x |
| `f64c` | `numpy.dot` | 468,782 | 737,116 | 1.57 x |
| `f32c` | `numpy.vdot` | 610,647 | 1,032,112 | 1.69 x |
| `f64c` | `numpy.vdot` | 437,204 | 749,826 | 1.72 x |
| `f64` | `scipy.jensenshannon` | 15,597 | 38,129 | 2.44 x |
| `f32` | `scipy.jensenshannon` | 15,436 | 234,427 | 15.19 x |
| `f16` | `scipy.jensenshannon` | 8,381 | 213,824 | 25.51 x |
| `f64` | `scipy.kl_div` | 49,725 | 61,399 | 1.23 x |
| `f32` | `scipy.kl_div` | 47,714 | 464,078 | 9.73 x |
| `f16` | `scipy.kl_div` | 36,418 | 422,291 | 11.60 x |
| `b8` | `scipy.hamming` | 836,733 | 11,655,827 | 13.93 x |
| `b8` | `scipy.jaccard` | 395,086 | 10,229,237 | 25.89 x |
|
