NumKong: 2'000 Mixed Precision Kernels For All 🦍

These are a few lines of celebratory “proud-dad” rumblings and highlights from my largest open-source release to date. I’m killing my SimSIMD project and re-launching under a new name — NumKong — StringZilla’s big brother. Over 2'000 SIMD kernels for mixed precision numerics, spread across 200'000 lines of code & docstrings, in 7 languages. One of the largest collections online — pretty much the same size as OpenBLAS, the default NumPy BLAS (Basic Linear Algebra Subprograms) backend (detailed comparison below).

What’s inside?

• RISC-V Vector Extensions, Intel AMX & Arm SME Tiles
• From Vectors to Matrices and Higher-rank Tensors
• From BFloat16 and Float16 to Float6 — E3M2 & E2M3 on any CPU
• Native Int4 & UInt4 Dot Products via Nibble Algebra
• Neumaier & Dot2 for higher-than-BLAS precision
• Ozaki Scheme for Float64 GEMMs via Float32 Tile Hardware
• Haversine & Vincenty for Geospatial — 5'300x faster than GeoPy
• Kabsch & Umeyama Mesh Alignment — 200x faster than BioPython
• Fused MaxSim for ColBERT — GPU-Free Late Interaction Scoring
• WebAssembly SIMD backend for AI Sandboxes, Edge, & Browsers
• C 99, C++ 23, Rust, Swift, JavaScript, GoLang, & Python 🐍

All of that tested against in-house 118-bit floating point numbers and heavily profiled for both numerical stability and speed! Here’s a preview of performance numbers for the most boring part — GEMM (General Matrix Multiply)-like batched dot products:

Those are single-threaded numbers for Intel Xeon4 CPUs powering mainstream Nvidia DGX-H100 servers — the workhorse of GenAI in 2025/6. NumKong makes different tradeoffs around speed vs accuracy, and a big part of the article is about the strategy of prioritizing one above the other.

Built for USearch, Released for Everyone

And no, the scale wasn’t the hard part — correctness, portability, and UX were. I started this release 3 years ago, when I first got access to Intel Xeon4 (Sapphire Rapids) CPUs. I opened the #220 Pull Request in 2024… and it’s already 2026. Around 900 commits in, CI finally passed for the first time; another 200 patches later, it was ready to merge 😅 I rewrote it several times to make sure it’s compatible with the evolution of Unum’s USearch — the search engine it was designed to accelerate.

When SimSIMD was first integrated into USearch, it was a little-known open-source project with an ambition. Now, it’s almost equally little-known, but with bindings for 14+ programming languages it powers vector search in ClickHouse, DuckDB, ScyllaDB, TiDB, Yugabyte, MemGraph, government and intelligence agencies, and several frontier AI labs — running on well over 100 Million, possibly over a Billion devices worldwide, from mobile phones to 10 kW mega-servers. I’m using it for the design of yet-to-be-released USearch v3, but you can already apply it elsewhere, like Albumentations team does for Image Processing.

Tiled Multiply-Accumulate on Every Chip

RISC-V

The saddest part of this story may just be the state of RISC-V — so let’s start at the bottom and work up.

RISC-V is the open-source Instruction Set Architecture that has made waves online and holds great promise for democratizing chip design. Sadly, even in 2026, it’s still far from usable. Even more disappointing, the driving force behind its growing adoption in CPUs (as opposed to external accelerators) isn’t technical merit — it’s growing geopolitical tensions between the US, China, Europe, Russia, and the rest of the world. Politics aside, what’s the state right now? Where can we find RISC-V cores and which of those have SIMD (Single Instruction, Multiple Data) extensions like RVV (RISC-V Vector) to enable advanced parallel processing?

Meanwhile, NVIDIA ships 1B+ RISC-V cores per year embedded in GPUs for power management — not for compute, but a telling sign of the ISA’s reach.

No public cloud offers RVV 1.0 hardware yet — Scaleway’s EM-RV1 with T-Head C910 is the only commercial option, stuck on the draft 0.7.1 spec. The gap to 1.0 is painful: binary-incompatible encodings, no fractional LMUL, no tail/mask-agnostic policies, different vsetvl semantics. Worse, there’s no ratified matrix extension yet — unlike Intel AMX or Arm SME, you can’t do 2D tiled matmuls, and BFloat16 requires the “Zvfbfwma” extension that C910 doesn’t have. That said, the instruction set is already humongous — as many have pointed out, “Reduced” doesn’t really belong in “RISC-V”.

RISC-V RVV vocabulary is quite simple compared to AVX-512, but when you look at the combinatorially exploding number of LMUL × datatype × policy combinations, it starts looking quite scary:

• AVX-512 ≈ 5.2k intrinsics
• Arm SVE/SVE2 ≈ 9.2k
• RVV 1.0 ≈ 71.5k

... excluding…

— Ash Vardanian (@ashvardanian) February 14, 2026

Despite all that, RVV does have unique strengths worth exploiting:

• vlseg/vsseg — segment loads that deinterleave AoS (complex numbers, RGB) directly into registers
• viota + vcompress — stream compaction in 3 instructions vs ~10 on AVX-512
• vfwredusum — widening reduction without the horizontal shuffle dance

What does work well: vfwmacc for f16 × f16 → f32 and vwmacc for i8 × i8 → i32 widening dot products. Even more interesting, vfwmacc_vv_f64m2 computes f64 += f32 × f32 in a single instruction with no intermediate rounding — the multiply happens at full Float64 width. Neither x86 nor SVE has an equivalent; on those ISAs you must widen both operands first, then FMA, eating two extra instructions and an intermediate rounding step.

Here are some of the interesting things that worked on RISC-V better than on other ISAs:

• nk_reduce_moments horizontal accumulations over arbitrarily strided data, where we may be computing the L2 norm of a column in a row-major matrix layout — the RVV kernel may use a combination of __riscv_vlse32_v_f32m1 strided loads and __riscv_vfwmacc_vv_f64m2_tu widening FMA in the hot loop
• nk_reduce_minmax horizontal reductions tracking positions in arbitrary size arrays, where the compared objects and the offsets have clearly different widths — the RVV kernel may use vfloat32m1_t for incoming floats and a wider vuint64m2_t to track positions
• nk_rmsd, nk_kabsch, nk_umeyama kernels for computational geometry with applications in Biology and Chemistry leverage RVV’s segmented loads and widening/narrowing logic for tight iterative algorithms like SVD — details in the mesh alignment section

Thanks to QEMU, I was able to validate all kernels for correctness, but it’s impossible to make throughput claims without hardware. So let’s switch to more practical cases.

Intel AMX and the Future Beyond AVX10.2

Intel was the first to bring GPU-style tensor cores to mainstream CPUs. Advanced Matrix Extensions (or AMX) provide massive 8x 1 KB tile registers (TMMs) and a dedicated TMUL unit for tiled matmuls. Conceptually similar to scheduling NVIDIA’s tensor cores, but much easier to program. Xeon4 supports bf16 × bf16 → f32 and i8 × i8 → i32. Granite Rapids adds f16 × f16 → f32. Some Xeon variants even ship with HBM, further blurring the CPU/GPU line.

1

_tile_dpbf16ps(0, 1, 2);  // TMM0 += TMM1 × TMM2 (BFloat16 → Float32)

Important to note, the first and the second multiplication arguments are ordered differently. More on this in the GEMMs section.

For NumKong users, the biggest value of those instructions will come from using:

• dots_packed_i8, dots_packed_bf16 for BLAS-like GEMMs
• dots_symmetric_i8, dots_symmetric_bf16 for BLAS-like SYRKs
• angulars_packed_bf16, euclideans_symmetric_i8, angulars_symmetric_e2m3, and other batched distance calculations and obscure numeric types with overlapping AMX and AVX-512
• maxsim_packed_f32, maxsim_packed_bf16 for scoring late-interaction ColBERT-style document embeddings

For now, those tiled dot-product instructions are limited to server hardware on the x86 side, but not for long. Intel and AMD are standardizing new ISA extensions that may end up on the consumer chips as well. Until then, NumKong now has separate backend families for Alder Lake and Sierra Forest CPUs.

• Alder Lake and its newer AVX VNNI variants are broadly available on laptops, resulting in up to 2x throughput improvements for heavily quantized USearch indexes compared to the pure AVX2 Haswell baselines.
• Sierra Forest brings AVX VNNI variants with symmetric Int8 or UInt8 input pairs, available on servers with up to 144 physical cores and up to 288 cores in a dual-socket configuration.

Apple’s SME — The Best ISA for Mixed-Precision Numerics

Ash: What’s the most efficient hardware for quantum simulations? Anyone: Some major server CPU tuned for a supercomputer, right? Ash: The last iPad :)

Apple has some of the most confusing hardware on the market. Every M4 chip ships at least three different units that can all do matrix multiplication: the CPU cores (now with Arm SME2, replacing proprietary AMX), a 38 TOPS Neural Engine (or ANE, usable only through CoreML), and the GPU via Metal compute shaders. Multiple options, each with a different programming model, different precision support, and no clear guidance from Apple on when to use which.

Still, the CPU part alone is pretty cool. Apple is the first hardware vendor to ship Scalable Matrix Extensions (or SME) to the market — starting with M4. SME combines a “Streaming SVE” subset with outer-product matrix ops, accumulating into persistent ZA registers. It supports more numeric types than Intel’s AMX and is much more composable if you are implementing something more than a vanilla dense matrix-multiplication.

1

svfmopa_za32_f16_m(0, predicate, predicate, tile_a, tile_b);  // za += outer_product(tile_a, tile_b)

This may look similar to Intel AMX, but it’s not. More on this in the GEMMs section.

The next versions of SME are supposed to bring LUTI2/LUTI4 lookup tables and full SVE compatibility. I expect it to be a game changer for sparse numerics and advanced algorithms — if only there were a 100+ core server variant. One thing to note: using SME requires careful CPU state switching to and from streaming mode, which isn’t free. You can’t mix Streaming SVE code with NEON and your typical LibC code. Still, this is the most programmable tiled hardware I’ve ever used, which will translate into gains for all the same kernel families as Intel AMX above, but also:

• nk_maxsim_packed on SME is just beautiful — on the fly GEMM-like outer-products over column-major packed matrices, then updates a running argmax with SVE compares/selects, and only does a final horizontal reduction at the end
• nk_dots_packed_u1_smebi32, nk_hammings_packed_u1_smebi32, nk_jaccards_packed_u1_smebi32 loads unpacked A rows horizontally into ZA0, reads them back vertically, and feeds those columns into svbmopa_za32_u32_m achieving 4'027 gso/s (or 4+ TOPS as most of the industry spells it) on a single core for 4096³ dense input matrix — possibly a game changer for Graph Algorithms, almost 10x an already fast tiled GEMM-like NEON kernel for the same task!
• nk_bilinear_f32c_smef64 kernel for double-precision bilinear forms for single-precision complex numbers is just marvelous — it stages real and imaginary parts separately, then uses FMOPA plus FMOPS for the subtracting complex term. I’ve spent a few thousand $ setting up all the AWS instances to validate/test this logic, and only realized that I forgot to get the numbers for this kernel after I’ve returned the dedicated hosts. Let’s hope it works as well as it looks!

This composability makes Arm SME + SVE combo the most convenient platform for programming advanced AI architectures. Even for vanilla “Transformers” (that I hate, but still occasionally release with my colleagues), composing GEMM + SoftMax + GEMM on Apple M4 and M5 CPUs is very promising.

How Hardware Converges

Every major vendor is arriving at the same answer — tiled mixed-precision multiply-accumulate — just with different register files, predicate models, and memory hierarchies:

CPUs and GPUs look more alike every generation. But unlike the somewhat specialized Graphics Processing Unit, the Central Processing Unit can’t always provide the same level of throughput as a task-specific accelerator. In a modern data-center its role is shifting towards connecting sub-systems and guaranteeing correctness. That was one of the guiding principles behind NumKong — precision of the numerics has to be sufficient first, and only then do we chase MKL, OpenBLAS, and cuBLAS throughput. When multiplying a 1'000 by 1'000 matrix, it’s not that big of a deal, but when you are scaling attention beyond 10 Million tokens, or vector search beyond 10 Billion vectors on each machine, numerical stability becomes a big deal.

WebAssembly & Relaxed SIMD

There is one more “platform” that doesn’t fit neatly into the hardware table above — the browser. WebAssembly’s Relaxed SIMD proposal, now part of the Wasm 3.0 standard, trades strict determinism for hardware-native fast paths. Chrome 114+ and Firefox 145+ ship it by default; Safari still has it behind a flag. WASM SIMD is fixed at 128-bit, but the JIT lowers each instruction to the best native path available:

NumKong compiles to WASM via Emscripten and Cranelift, covering every kernel with the _v128relaxed suffix — dot products, batched GEMMs, geospatial, mesh alignment, and more. In the browser, no install needed — just a <script> tag:

1
2
3
4
5
6
7
8

<script type="module">
import { dot, euclidean } from 'https://cdn.jsdelivr.net/npm/numkong@7/dist/numkong.js';

const query = new Float32Array([1.0, 2.0, 3.0]);
const doc = new Float32Array([4.0, 5.0, 6.0]);
console.log(dot(query, doc));          // 32 — SIMD-accelerated, client-side
console.log(euclidean(query, doc));    // 5.196...
</script>

The entire WASM bundle is under 500 KB — smaller than most JavaScript frameworks.

Possible improvement directions for backends: Loongson LAPX (#317), IBM Power VSX & MMA (#318), and Arm FP8 on NVIDIA’s Vera/Olympus cores (#319). Intel’s Nova Lake may also bring native FP16 dot products to the consumer desktop.

Precision Spectrum: From Float118 to Float4

IEEE 754 was defined in 1985 and for many years the “single-precision” and “double-precision” numerics it standardized were enough. Four decades later, every time Jensen Huang appears on stage with a new FLOPS number, you must ask yourself — which exact numeric type is he referring to? Transistor cost and density is still improving, but not nearly as much as perceived. So we as an industry shift towards smaller numeric types. For brevity, in this article, we’ll only look at numerics for these input types:

Float118 is not an IEEE type — it is a “double-double” representation that pairs two Float64 values using Knuth two-sum and FMA for error-free transformations, yielding ~106 bits of effective mantissa (~32 decimal digits). The range matches Float64, since both components share the same exponent field, but precision is roughly double. NumKong uses it internally as a ground-truth reference for validating all other kernels. How does it compare to other extended-precision options?

Float6 types follow the OCP MX v1.0 specification — each value occupies 6 bits stored in an 8-bit byte, with the upper 2 bits unused. E3M2 has no NaN and supports infinities at ±28; E2M3 has neither NaN nor infinities, with ±7.5 as the maximum representable value. Int4 and UInt4 are packed as nibble pairs — two 4-bit values per byte, with the low element in bits 0–3 and the high element in bits 4–7.

How many of the mainstream machine learning numerics projects support these types? To my surprise, with some tweaking — quite many, thanks to Google’s ml_dtypes package that almost nobody knows about. So if you want to deal with bfloat16 values in NumPy matrices, you can use those extensions:

1
2
3
4
5

from ml_dtypes import bfloat16
import numpy as np

arr = np.array([1.0, 2.0, 3.0], dtype=bfloat16)
result = arr @ arr  # Dot product, but painfully slow!

Under the hood this implements NEP 42 to serially convert numbers to a framework-friendly old-school float32. Let’s rephrase the question: in which of those numeric types can you perform a hardware-accelerated matrix multiplication — AI’s most important operation — on CPUs, GPUs, or TPUs?

✅ = standard API, ⚡ = hardware-accelerated via specialized API, ❌ = not supported or serial fallback

A lot of red on this table. At best, support is hardware-specific, dependent on access to $10K+ expensive data-center GPUs & TPUs, and contingent on downloading a gigabyte-sized framework. And that’s in Python, by far the most mature ecosystem for machine learning. Things are much worse if you are developing in C/C++, Rust, Swift, or other programming languages…

Tensors in Python

Remember ml_dtypes above? NumPy can represent BFloat16 with that plugin, but arr @ arr falls back to serial f32 casts. NumKong accepts those same buffers — zero copy — but routes through SIMD kernels. PyTorch tensors also work directly via the buffer protocol: nk.dot(torch_a, torch_b) just works, no conversion. Slice a column from a row-major matrix, and argmin or moments still fire SIMD — 2.45x faster than np.argmin on strided columns, covered in the reductions section. All batched kernels release the GIL, and the METH_FASTCALL calling convention avoids PyArg_ParseTupleAndKeywords overhead entirely.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

import torch, numkong as nk

embeddings = torch.randn(10_000, 768, dtype=torch.bfloat16)
nk.dot(embeddings[0], embeddings[1])                  # buffer protocol, zero copy from PyTorch

packed = nk.dots_pack(embeddings, dtype=nk.bfloat16)   # pack once, reuse across query batches
scores = nk.dots_packed(embeddings[:128], packed)     # 128×10K batched GEMM

matrix = nk.Tensor(embeddings.float().numpy())        # float32 for NumPy interop
column = matrix[:, 0]                                 # strided view — no copy
column.argmin()                                       # SIMD reduction on strided data

CUDA unified memory opens up a neat debugging trick. Wrap a live GPU tensor via nk.from_pointer, and you can scan layers of a running network without copying anything back to host explicitly. Hunting for the layer that started diverging after a quantization pass becomes a one-liner.

1
2
3
4
5
6

model = load_my_model().cuda()
for name, param in model.named_parameters():
    view = nk.from_pointer(param.data_ptr(), tuple(param.shape), nk.bfloat16, owner=param)
    norms = view.norm(axis=0)                        # column-wise L2 norms, SIMD-accelerated
    if norms.max() > 1e3:                            # outlier detector for post-quantization debugging
        print(f"{name}: norm outlier at {norms.argmax()} = {norms.max():.1f}")

Tensors in C

BLAS was standardized in 1979, originally implemented in Fortran, and every scientific computing package on earth links against it. OpenBLAS — the default NumPy backend — maintains 2'456 kernel files across 1.97M lines of code, 51% of it hand-written assembly, running on 15 CPU architectures from x86 to SPARC to s390x. GEMM + copy + TRSM account for 58% of all those kernels — for dense Float32 and Float64 matrix multiplication, nothing comes close. The intro table shows this: OpenBLAS hits 65.5 gso/s on Float64 GEMMs where NumKong reaches 8.6 gso/s, trading throughput for sub-ULP precision.

The type landscape, however, hasn’t kept up. Complex-double alone is 31% of all OpenBLAS files, while Float16 gets two (conversion stubs, no compute) and Float8 gets zero. sdsdot (f32 × f32 → f64 → f32) remains the only mixed-precision operation from the original standard. A Dongarra-led “BLAS G2” proposal in 2016–2019 tried to standardize half/int/quad precision, but no formal standard was ratified — each vendor bolted on their own extensions instead:

Tensors in C++23

Consider a common LLM inference task: you have Float32 attention weights and need to L2-normalize each row, quantize to E5M2 for cheaper storage, then score queries against the quantized index via batched dot products. In CBLAS, there is no norm-then-quantize primitive — you’d loop over columns with cblas_snrm2, manually divide each row, cast element-by-element, and hand-roll the batched GEMM. Eigen can do m.colwise().norm() but stops at float and double — no E5M2, no sub-byte types, no runtime SIMD dispatch.

NumKong’s C++ header wraps the C ABI in a zero-cost tensor template that handles the full pipeline:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20

namespace nk = ashvardanian::numkong;

// Float32 attention weights — 1000 vectors × 768 dimensions
auto weights = nk::tensor<nk::f32_t>::try_full({1000, 768}, nk::f32_t{1});

// Row-wise L2 norms via moments, then normalize each row in-place
auto [sums, sumsqs] = nk::try_moments(weights.view(), /*axis=*/1);
for (std::size_t i = 0; i < weights.extent(0); ++i) { // or via .rows_spans() iterator
    float inv_norm = 1.0f / std::sqrt<float>(sumsqs[i]), zero = 0.0f;
    auto row = weights.row(i).as_vector();
    nk::scale(row.data(), row.size(), &inv_norm, &zero, row.data());
}

// Quantize f32 → e5m2, pack, and score queries via batched GEMM
auto quantized = nk::tensor<nk::e5m2_t>::try_zeros({1000, 768});
nk::cast(weights.view().data(), 1000 * 768, quantized.span().data());
auto packed = nk::packed_matrix<nk::e5m2_t>::try_pack(quantized.view().as_matrix());
auto queries = nk::tensor<nk::e5m2_t>::try_zeros({128, 768});
auto scores = nk::tensor<nk::f32_t>::try_zeros({128, 1000});
nk::dots_packed(queries.view(), packed, scores.span());

Slicing uses C++23 variadic operator[] with marker types:

• t[i, j] returns f32_t&, while
• t[i, j, nk::slice] returns a rank-zero tensor_view, and
• t[nk::all, j, nk::slice] returns a strided tensor_view.

The return type changes at compile time, no runtime costs unlike Python. Sub-byte types keep the same syntax: tensor<i4x2_t>[idx] returns sub_byte_ref<i4x2_t> — a proxy that reads and writes a nibble. All scalar types — f16_t, bf16_t, e4m3_t, i4x2_t and friends — have std::formatter specializations, so std::format("{:#}", val) prints 3.14 [0x4248] and std::format("{:b}", val) prints the raw bits. Eigen has none of that: no sub-byte types, no Float8/Float6, no signed strides, no runtime SIMD dispatch, no widening accumulators. It expects the compiler to auto-vectorize, which almost never happens for exotic types, and in most cases just bloats the binary. std::mdspan gives you layout + accessor but no operations and no sub-byte support; NumKong views interop via raw pointer handoff.

Tensors in Rust

The same pipeline in Rust is more concise — try_norm_axis and try_cast_dtype are first-class methods on Tensor:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17

use numkong::{configure_thread, Tensor, PackedMatrix, MomentsOps, ScaleOps, CastOps};
use numkong::types::e5m2;

configure_thread();
let mut weights = Tensor::<f32>::try_full(&[1000, 768], 1.0).unwrap();

// Normalize → quantize → pack → score
let norms = weights.try_norm_axis(1, false).unwrap();
for (i, mut row) in weights.axis_spans(0).unwrap().enumerate() {
    row.try_scale_tensor_into(1.0 / norms[i] as f32, 0.0, &mut row).unwrap();
}
let quantized = weights.try_cast_dtype::<e5m2>().unwrap();
let packed = PackedMatrix::try_pack(&quantized).unwrap();

// 128 queries against the packed index — batched GEMM, SIMD-accelerated
let queries = Tensor::<e5m2>::try_full(&[128, 768], e5m2::from(0.5)).unwrap();
let scores = queries.dots_packed(&packed);

For comparison, ndarray — Rust’s most popular tensor library — supports only f32 and f64, has no SIMD dispatch, no sub-byte types, and no packed GEMM. NumKong mirrors the C++ container hierarchy — Tensor<T, A> owns, TensorView and TensorSpan borrow — but all operations are trait-based and monomorphized with zero dispatch overhead. Sub-byte types like i4x2 and u1x8 use DimRef/DimMut proxy accessors with read-modify-write on Drop, and allclose gives tolerance-based comparison via the AllCloseOps trait — surprisingly absent from both nalgebra and ndarray.

Possible improvement directions for SDKs: Zig bindings, a cheaper FFI interface for Go (#28), and better compatibility with NumPy.

Kernel Design Patterns

Repeating all the documentation here felt silly, but so would burying it in READMEs and forgetting about it until the next iteration. So here’s a scoop of the most important optimizations missing from previous library versions, starting with the most embarrassing one.

Int8 and UInt8 Symmetric Dot-Products via VNNI

Scope: nk_dot_(i8|u8)_(ice|sierra).

Intel’s DPBUSD instruction computes a dot product of 8-bit integers — but it expects one unsigned and one signed operand. If both your inputs are signed, or both unsigned, you have a problem. The naive fix is to upcast everything to 16-bit via cvtepi8_epi16 and use VPDPWSSD — but widening runs on port 5, and you need two widenings per iteration, so port 5 becomes the bottleneck while port 0 sits half-idle.

The better fix is “algebraic”. XOR-ing a signed byte with 0x80 flips the sign bit, mapping [-128, 127] to [0, 255] — which is just adding 128. So DPBUSD(a ⊕ 0x80, b) computes (a+128)·b instead of a·b, and the correction is trivial: subtract 128 × Σb at the end. The unsigned case is symmetric: bias b instead and compensate with 128 × Σa. WASM’s relaxed_dot_i8x16_i7x16_add faces the same mismatch — it constrains one operand to 7 bits [0, 127] so both x86’s unsigned × signed vpdpbusd and Arm’s signed × signed sdot produce identical results, and NumKong’s WASM backend uses a similar decomposition to handle full-range signed inputs.

The trick is how we accumulate those correction sums. SAD — sum of absolute differences against zero — gives us Σb cheaply, and it fires on port 5 while DPBUSD occupies port 0. The two instructions run in parallel every cycle, making the compensation essentially free.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

// Signed i8 × i8: bias a to unsigned, accumulate sum(b) for correction
__m512i a_biased = _mm512_xor_si512(a_i8x64, _mm512_set1_epi8(0x80));
sum_ab = _mm512_dpbusd_epi32(sum_ab, a_biased, b_i8x64);            // (a+128)·b @ port 0
__m512i b_unsigned = _mm512_xor_si512(b_i8x64, _mm512_set1_epi8(0x80));
sum_b = _mm512_add_epi64(sum_b, _mm512_sad_epu8(b_unsigned, zeros)); // Σb via SAD @ port 5

// Unsigned u8 × u8: bias b to signed, accumulate sum(a) for correction
__m512i b_signed = _mm512_xor_si512(b_u8x64, _mm512_set1_epi8(0x80));
sum_ab = _mm512_dpbusd_epi32(sum_ab, a_u8x64, b_signed);          // a·(b-128) @ port 0
sum_a = _mm512_add_epi64(sum_a, _mm512_sad_epu8(a_u8x64, zeros)); // Σa via SAD @ port 5

After the loop, the epilogue is a single shift-and-subtract — 128 × Σb is just Σb << 7:

1
2

__m128i correction_i32x4 = _mm_slli_epi32(b_sums.xmm, 7);       // × 128
results->xmm = _mm_sub_epi32(biased_i32x4, correction_i32x4);   // exact result, no rounding

The new path processes 64 elements per iteration instead of 32. Here is the full picture:

Sierra Forest made this entire dance obsolete. Intel’s AVX-VNNI-INT8 extension adds VPDPBSSD for native signed × signed and VPDPBUUD for unsigned × unsigned — no algebraic transform, no compensation terms, just the dot product you wanted. The Ice Lake workaround remains relevant for the millions of Xeon4 and earlier servers already deployed.

The same algebraic trick extends to 4-bit integers. Each byte packs two signed Int4 values as nibbles in [-8, 7]. XOR-ing with 0x08 maps them to unsigned [0, 15], and the signed product expands as:

$$ (a \oplus 8 - 8)(b \oplus 8 - 8) = (a \oplus 8)(b \oplus 8) - 8(a \oplus 8 + b \oplus 8) + 64 $$

Extract low and high nibbles with AND + shift, XOR both to unsigned, then fire two DPBUSD calls per iteration — one for each nibble position. The correction sums are accumulated the same way, and the final result is signed_dot = unsigned_dot - 8 × (Σa' + Σb') + 64 × n.

Compensated Summation: Dot2 in SIMD

Scope: nk_dot_f64_(sve|neon|rvv).

OpenBLAS and MKL accumulate Float64 dot products with naive summation — rounding errors grow as O(√n), reaching 56 mean ULP (Units in the Last Place) at 4096³ matrix size. NumKong’s Dot2 implementation hits 0 ULP at the same size. The algorithm, from Ogita, Rump, and Oishi, tracks every rounding error alongside the main sum, achieving O(1) error growth regardless of vector length.

It relies on two error-free transforms. TwoProd: FMA computes a×b at full internal precision, so fma(a, b, -product) recovers the exact rounding residual of the multiplication. TwoSum: a similar five-operation dance recovers the exact rounding residual of an addition. Both residuals get accumulated into a separate compensation register that rides alongside the main sum.

1
2
3
4
5
6
7
8
9

void nk_f64_dot2_(nk_f64_t *sum, nk_f64_t *comp, nk_f64_t a, nk_f64_t b) {
    nk_f64_t product = a * b;
    nk_f64_t product_error = fma(a, b, -product);   // TwoProd: exact multiply residual
    nk_f64_t new_sum = *sum + product;
    nk_f64_t recovered = new_sum - *sum;            // TwoSum: exact addition residual
    nk_f64_t sum_error = (*sum - (new_sum - recovered)) + (product - recovered);
    *sum = new_sum;
    *comp += sum_error + product_error;
}

The SIMD main loop is identical — TwoProd+TwoSum across all lanes in parallel, nothing surprising. The hard part is the horizontal reduction: you hold two vector registers of partial results and need to fold them into one scalar without losing precision.

On NEON with its fixed 2 Float64 lanes, this is trivial — parallel TwoSum on both lanes, extract with vgetq_lane_f64, one scalar TwoSum to finish. On SVE and RVV, vector lengths are unknown at compile time. The solution is a log₂(VL) tree: at each level, extract the upper half via svtbl or vslidedown, TwoSum it with the lower half, propagate the rounding error downward. Out-of-range indices return zero on both ISAs, so the shrinking upper half is harmless.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18

svfloat64_t merged = svadd_f64_x(pg, partial_sum, compensation);
svfloat64_t addend = svsub_f64_x(pg, merged, partial_sum);
svfloat64_t error = svadd_f64_x(pg,
    svsub_f64_x(pg, partial_sum, svsub_f64_x(pg, merged, addend)),
    svsub_f64_x(pg, compensation, addend));
for (unsigned half = svcntd() / 2; half > 0; half >>= 1) {
    svuint64_t upper_idx = svadd_n_u64_x(pg, svindex_u64(0, 1), half);
    svfloat64_t upper_merged = svtbl_f64(merged, upper_idx);
    svfloat64_t upper_error = svtbl_f64(error, upper_idx);
    svfloat64_t halved = svadd_f64_x(pg, merged, upper_merged);
    svfloat64_t halved_addend = svsub_f64_x(pg, halved, merged);
    svfloat64_t rounding_error = svadd_f64_x(pg,
        svsub_f64_x(pg, merged, svsub_f64_x(pg, halved, halved_addend)),
        svsub_f64_x(pg, upper_merged, halved_addend));
    merged = halved;
    error = svadd_f64_x(pg, svadd_f64_x(pg, error, upper_error), rounding_error);
}
return svlastb_f64(first_lane, merged) + svlastb_f64(first_lane, error);

Casting via Tabular Lookups on x86 and Arm

Scope: nk_cast and pretty much every other kernel.

When your numeric type has few enough distinct unsigned magnitudes, a single table lookup replaces all the bit-shifting arithmetic of a traditional float conversion. The question is where the cutoff falls — and it differs on x86 vs Arm because their LUT instructions have different capacities. x86 AVX-512BW has VPERMUTEXVAR_EPI16: 32 entries of 16-bit values in one ZMM register, chainable via VPERMI2W for larger tables. Arm NEON has VQTBL2Q: 32 entries of 8-bit values across two registers, with out-of-range indices returning zero — useful for clamping, but impractical to chain for 128+ entries.

The cleanest path is E2M3: every possible 5-bit magnitude fits in one register, subnormals included. Mask the magnitude, look it up, shift the sign bit into position, OR them together — four operations, no branching, no blending.

1
2
3
4
5

// E2M3 → BF16 on x86: full 32-entry LUT, one permutexvar
__m512i magnitude = _mm512_and_si512(widened, _mm512_set1_epi16(0x1F));
__m512i sign = _mm512_and_si512(widened, _mm512_set1_epi16(0x20));
__m512i result = _mm512_permutexvar_epi16(magnitude, lut_bf16x32);
result = _mm512_or_si512(result, _mm512_slli_epi16(sign, 10)); // sign bit 5 → bit 15

E4M3 and E5M2 have 128 unsigned magnitudes — too many for one LUT. Normals get arithmetic conversion via shift-and-add, while the handful of subnormals still go through a small lookup table. On Arm, where chaining VQTBL2Q is expensive, even subnormals use arithmetic — shifts, adds, and blends.

LUT-free arithmetic upcasts via Giesel-style float-multiplication tricks are being explored but depend on rounding-mode control that conflicts with NumKong’s default denormal-to-zero policy.

Use BFloat16 or Float16 for Float8 Arithmetic?

Scope: nk_dot_(e4m3|e5m2)_(genoa|neonfhm).

No CPU has a native Float8 dot product yet, so you must upcast to something that does. The two candidates are BFloat16 and Float16 — both lossless for E4M3 normals, since 3 mantissa bits fit comfortably in either 7 or 10. NumKong uses BFloat16 on x86 and Float16 on Arm, for different reasons on each side.

On x86, VDPBF16PS fuses two BFloat16 multiplies per 32-bit lane — doubling throughput compared to a single-multiply instruction. The upcast from E4M3 goes through the LUT+arithmetic path from the previous section.

1
2
3

a_bf16x32 = nk_e4m3x32_to_bf16x32_icelake_(a_e4m3x32);
b_bf16x32 = nk_e4m3x32_to_bf16x32_icelake_(b_e4m3x32);
sum_f32x16 = _mm512_dpbf16_ps(sum_f32x16, a_bf16x32, b_bf16x32);

On Arm, there is no BFloat16 dot product instruction, but FMLAL from the FHM extension provides a widening f16 × f16 → f32 FMA that fires at 2-4 per cycle on modern cores. And the upcast is cheaper: E4M3’s 4-bit exponent maps into Float16’s 5-bit exponent with a single shift, so the conversion is pure arithmetic — no LUT needed.

1
2
3
4
5
6

nk_e4m3x16_to_f16x8x2_neon_(vld1q_u8(a), &a_low, &a_high); // shifts + adds, no LUT
nk_e4m3x16_to_f16x8x2_neon_(vld1q_u8(b), &b_low, &b_high);
sum_f32x4 = vfmlalq_low_f16(sum_f32x4, a_low, b_low);      // c[0:4] += a[0:4] × b[0:4]
sum_f32x4 = vfmlalq_high_f16(sum_f32x4, a_low, b_low);     // c[0:4] += a[4:8] × b[4:8]
sum_f32x4 = vfmlalq_low_f16(sum_f32x4, a_high, b_high);    // c[0:4] += a[8:12] × b[8:12]
sum_f32x4 = vfmlalq_high_f16(sum_f32x4, a_high, b_high);   // c[0:4] += a[12:16] × b[12:16]

Use Int16 and Int8 for Float6 Arithmetic?

Scope: nk_dot_(e2m3|e3m2)_(haswell|alder|sierra|icelake|neonsdot).

Every E2M3 value multiplied by 16 is an exact integer in [-120, +120], fitting a signed i8. Why 16? E2M3 has bias=1 and 3 mantissa bits, so the smallest nonzero subnormal is 1/8 — multiplying by 16 clears the denominator for every representable value. This means we can replace floating-point dot products with integer ones and divide by 16×16=256 at the very end — zero rounding error.

A 32-entry LUT maps each 5-bit unsigned magnitude to its scaled integer. On Arm, VQTBL2Q does the lookup; on x86, VPERMB does the same across a full ZMM register. Then we XOR the sign bits of a and b, negate b where they differ, and feed the result into an integer dot product. On Arm, that is VQTBL2Q + SDOT:

1
2
3
4

uint8x16_t a_mag = vqtbl2q_u8(lut_pair, vandq_u8(a, mask_0x1F));
uint8x16_t b_mag = vqtbl2q_u8(lut_pair, vandq_u8(b, mask_0x1F));
int8x16_t b_signed = vbslq_s8(negate_mask, vnegq_s8(b_mag), b_mag);
sum_i32x4 = vdotq_s32(sum_i32x4, a_mag, b_signed); // c[0:4] += a[k:k+4] · b[k:k+4]

On x86, VPERMB + VPDPBUSD process 64 elements per iteration:

1
2
3
4

__m512i a_unsigned = _mm512_permutexvar_epi8(a_magnitude, lut_u8x64);
__m512i b_unsigned = _mm512_permutexvar_epi8(b_magnitude, lut_u8x64);
__m512i b_signed = _mm512_mask_sub_epi8(b_unsigned, negate_mask, zeros, b_unsigned);
sum_i32x16 = _mm512_dpbusd_epi32(sum_i32x16, a_unsigned, b_signed);

Both paths end with one division: (float)reduce_add(sum) / 256.0f — exact, because both operands were scaled by 16 and the integer arithmetic lost nothing.

E3M2 is the trickier sibling — its magnitudes reach 448, blowing past i8 range. So it uses the i16 path instead: same LUT lookup for the low byte via vqtbl2q_u8, a comparison vcgeq_u8(idx, 28) to generate the high byte, then vzip to assemble 16-bit values. vmlal_s16 accumulates the wider products into i32 — same zero-error principle, just one lane-width up.

Complex Dot Products: Deinterleave vs FCMLA

Scope: nk_(dot|vdot)_f32c_neon.

ARMv8.3 introduced FCMLA — a dedicated complex multiply-accumulate that processes interleaved real/imaginary pairs with a single instruction per rotation. Two vcmlaq calls with rot0 and rot90 should, in theory, replace four separate FMAs.

The alternative is to deinterleave first: vld2 splits interleaved complex pairs into separate real and imaginary registers, then four independent vfmaq instructions compute real += aᵣ×bᵣ, real -= aᵢ×bᵢ, imag += aᵣ×bᵢ, imag += aᵢ×bᵣ. On Apple M4 at n=4096, the deinterleaved path hits 39.7 GiB/s; FCMLA manages 17.1 GiB/s — 2.3x slower.

The reason is instruction-level parallelism. M4 has four SIMD pipes, and four independent vfmaq calls saturate all of them. FCMLA’s rot0 and rot90 variants have a data dependency — rot90 reads the result of rot0 — so the M4 cannot overlap them. Two dependent instructions on a 4-wide backend leave half the pipes idle.

NumKong’s complex kernels also upcast Float32 inputs into Float64 accumulators for better precision, and the four-pipe parallelism more than compensates for the doubled lane width. FCMLA offers neither the throughput nor the precision advantage on this microarchitecture.

Broader lesson: specialized instructions are designed for specific pipeline widths. On cores with fewer SIMD pipes, FCMLA may well win. Measure on your target hardware.

Fast Reductions for Strided Arrays

Scope: nk_reduce_*.

NumKong requires contiguous inputs for binary operations like dot products, but reductions on strided arrays still get SIMD. The use case: aggregating columns of a tall row-major matrix, or reducing a member field across an array-of-structures layout.

The key idea on AVX-512: instead of expensive gather instructions, do a contiguous load and mask out the bytes you don’t want. A precomputed 64-bit K-register mask selects every n-th byte. For stride=2, the mask is 0x5555555555555555 — every other byte, 32 elements per load. For stride=3, it is 0x9249249249249249 — 22 elements. All the way down to stride=16 with 4 elements, below which we fall back to scalar.

1
2
3
4
5
6

__mmask64 stride_mask = nk_stride_mask_u1x64_(stride);
nk_size_t step = _mm_popcnt_u64(stride_mask) * stride;
for (; idx + step <= total; idx += step) {
    __m512i data = _mm512_maskz_loadu_epi8(stride_mask, ptr + idx);
    // non-column bytes are zero — safe to feed into SAD, VNNI, etc.
}

On Arm, vld2q/vld3q/vld4q deinterleave 2/3/4-strided data directly into separate registers during the load — no masking needed, but limited to strides 2-4. The stride-3 case for XYZ point clouds is covered in detail in the mesh alignment section.

Once we have the strided data in registers, two families of reductions use it very differently.

reduce_minmax finds extrema and their positions without upcasting mini-floats. IEEE 754 floats have an order-preserving property: for positive values, the integer representation sorts the same way as the float value. Negative values need their magnitude bits flipped. A single XOR transforms any Float8 or Float6 byte into an unsigned integer that compares correctly — vminq_u8/vmaxq_u8 on Arm, _mm512_min_epu8/_mm512_max_epu8 on x86 — no upcast to Float16 or Float32, no floating-point compare.

1
2
3
4
5

// Float8 → order-preserving unsigned byte, one XOR per lane
__mmask64 negative = _mm512_test_epi8_mask(raw, _mm512_set1_epi8(0x80));
__m512i xor_pos = _mm512_set1_epi8(0x80);   // positive: flip sign bit
__m512i xor_neg = _mm512_set1_epi8(0xFF);   // negative: flip all bits
__m512i comparable = _mm512_xor_si512(raw, _mm512_mask_mov_epi8(xor_pos, negative, xor_neg));

reduce_moments computes sum and sum-of-squares for L2 norms — critical in ML normalization layers. For Float32 inputs, the accumulation widens to Float64: _mm512_cvtps_pd upcasts 8 floats, then _mm512_fmadd_pd accumulates x² directly in double precision, avoiding the catastrophic cancellation that plagues single-precision norms on long vectors. For integer inputs, the approach is different — SAD computes the biased sum while VPDPWSSD accumulates the sum-of-squares in one fused instruction. But integer accumulators eventually overflow. For i8 and i16 inputs, NumKong uses a divide-and-conquer strategy: once the element count exceeds what a 64-bit accumulator can safely hold, the array is split in half, each half reduced recursively, and the two 64-bit results merged with a saturating add.

The i64 case is trickier — there is nothing wider to accumulate into, and pairwise saturating addition silently loses information. Consider {INT64_MAX, INT64_MAX, -INT64_MAX} — the true sum is INT64_MAX:

1
2
3
4

int64_t inputs[] = {INT64_MAX, INT64_MAX, -INT64_MAX};
int64_t naive = inputs[0] + inputs[1] + inputs[2];      // UB: signed overflow on inputs[0]+inputs[1]
int64_t pairwise = sadd(sadd(0, inputs[0]), inputs[1]); // MAX → sadd(MAX, -MAX) = 0 ← WRONG
nk_reduce_moments_i64(d, 3, 8, &sum, &sumsq);           // 128-bit: 0 → MAX → 2MAX → MAX ← CORRECT

Early saturation erased the pending cancellation. NumKong emulates a 128-bit accumulator with sum_lower/sum_upper register pairs and manual carry propagation, clamping only once after the entire loop.

Vincenty with Masked Convergence

Scope: nk_vincenty_f64_(skylake|genoa).

Haversine gives you the great-circle distance — shortest path on a perfect sphere:

$$ d = 2r \arcsin\sqrt{\sin^2\frac{\Delta\varphi}{2} + \cos\varphi_1\cos\varphi_2\sin^2\frac{\Delta\lambda}{2}} $$

One closed-form evaluation, no iteration, easy to vectorize. But Earth is not a sphere — it is an oblate spheroid, roughly 21 km wider at the equator than pole-to-pole. Vincenty’s formula accounts for this flattening by iteratively refining an auxiliary longitude λ until convergence:

$$ \sin^2\sigma = (\cos U_2\sin\lambda)^2 + (\cos U_1\sin U_2 - \sin U_1\cos U_2\cos\lambda)^2 $$

where $U_1$, $U_2$ are reduced latitudes on the reference ellipsoid. The iteration converges in 3-8 steps for most point pairs, but degenerates for coincident points and near-antipodal cases — exactly the kind of variable-rate convergence that makes SIMD interesting.

The Haversine error from ignoring flattening is up to ~0.3%, which matters for surveying, aviation corridors, and high-precision geofencing. Vincenty is inherently ~10x more expensive per pair, so SIMD parallelism is the only way to keep it practical at scale.

Haversine and Vincenty have vastly different error bounds and behavior at critical points (antipodal, coincident, equatorial). The numbers below compare throughput only — not accuracy.

NumKong’s Vincenty in f64 → f64 is 15x faster than Rust geo and 1'800x faster than Python geopy — because 8 point-pairs iterate simultaneously in AVX-512. But those 8 pairs converge at different rates, and this is where the implementation gets interesting.

The solution is a convergence mask: __mmask8 converged_mask tracks which lanes are done, and the loop exits when all 8 bits are set. The mask is not just an optimization — converged lanes may have near-zero denominators that would produce NaN if allowed to keep iterating.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

__mmask8 converged_mask = 0;
__mmask8 coincident_mask = 0;
for (nk_u32_t iter = 0; iter < MAX_ITER && converged_mask != 0xFF; ++iter) {
    __m512d sin_lambda = nk_sin_f64x8_skylake_(lambda);
    // ... Vincenty iteration body ...
    coincident_mask = _mm512_cmp_pd_mask(sin_angular_dist, threshold, _CMP_LT_OS);
    sin_azimuth = _mm512_maskz_div_pd(_knot_mask8(coincident_mask),
        cos_u1_cos_u2_sin_lambda, sin_angular_dist);
    __mmask8 equatorial_mask = _mm512_cmp_pd_mask(cos_sq_alpha, eps, _CMP_LT_OS);
    quotient = _mm512_mask_div_pd(passthrough, _knot_mask8(equatorial_mask),
        two_sin_product, cos_sq_alpha);
    converged_mask |= _mm512_cmp_pd_mask(abs_delta, threshold, _CMP_LT_OS);
}

Two separate division-by-zero hazards need two different masked divide flavors. _mm512_maskz_div_pd zeroes the result for coincident points — two identical locations where sin of the angular distance vanishes. _mm512_mask_div_pd uses a passthrough value for equatorial cases where cos²α vanishes — the passthrough is chosen so the subsequent subtraction yields zero, keeping the iteration stable.

This pattern generalizes to any SIMD convergence loop — Newton-Raphson, iterative solvers, ray-sphere intersection. Track a mask of done lanes, guard every division with that mask, exit when full.

Mesh Alignment: Deinterleaving XYZ across ISAs

Scope: nk_(rmsd|kabsch|umeyama)_(f32|f64)_(neon|haswell|skylake|rvv).

RMSD measures how far apart two point clouds are on average — it’s the “are these similar?” check. Kabsch finds the optimal rotation to overlay one cloud onto another, minimizing that RMSD. Umeyama adds uniform scaling on top of Kabsch — useful when the two clouds differ in size, e.g. comparing a crystal structure to a docked ligand at different resolutions. All three operate on 3D point clouds stored as interleaved XYZ triplets — the standard Array-of-Structures layout. The first challenge in every kernel is getting the data out of AoS into separate X, Y, Z vectors for vectorized centroid and covariance computation. Every ISA does this differently, and the choice matters — deinterleaving is the inner loop’s first operation, so it sets the throughput ceiling.

NEON has hardware stride-3 loads. vld3q_f32 reads 12 contiguous floats and returns three 4-wide vectors — X, Y, Z separated in one instruction:

1
2
3
4

float32x4x3_t xyz_f32x4x3 = vld3q_f32(ptr); // 4 XYZ triplets → 3 vectors
*x_f32x4_out = xyz_f32x4x3.val[0];          // x0, x1, x2, x3
*y_f32x4_out = xyz_f32x4x3.val[1];          // y0, y1, y2, y3
*z_f32x4_out = xyz_f32x4x3.val[2];          // z0, z1, z2, z3

Haswell lacks stride-3 loads, so we use _mm256_i32gather_ps with pre-computed stride-3 indices [0,3,6,9,12,15,18,21] — three gathers offset by 0, 1, 2 for X, Y, Z respectively.

Skylake avoids gathers entirely with VPERMT2PS cross-register permutations. Load three 512-bit registers covering 48 floats (16 XYZ triplets), then six permutations separate X, Y, Z — 1.8x faster than scalar deinterleaving:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

__m512 reg0_f32x16 = _mm512_loadu_ps(ptr);      // floats  0-15
__m512 reg1_f32x16 = _mm512_loadu_ps(ptr + 16); // floats 16-31
__m512 reg2_f32x16 = _mm512_loadu_ps(ptr + 32); // floats 32-47

// X: 6 from reg0, 5 from reg1, 5 from reg2
__m512i idx_x_01_i32x16 = _mm512_setr_epi32(0,3,6,9,12,15, 18,21,24,27,30, 0,0,0,0,0);
__m512i idx_x_2_i32x16  = _mm512_setr_epi32(0,1,2,3,4,5,6,7,8,9,10, 17,20,23,26,29);
__m512 x01_f32x16 = _mm512_permutex2var_ps(reg0_f32x16, idx_x_01_i32x16, reg1_f32x16);
*x_f32x16_out = _mm512_permutex2var_ps(x01_f32x16, idx_x_2_i32x16, reg2_f32x16);
*y_f32x16_out = ... ; // similar code for Y
*z_f32x16_out = ... ; // similar code for Z

RVV uses segmented loads — vlseg3e32 returns a vfloat32m1x3_t tuple, and vget extracts each coordinate. The vector length adapts dynamically via vsetvl, so the same code works on any RISC-V implementation:

1
2
3
4

vfloat32m1x3_t a_f32m1x3 = __riscv_vlseg3e32_v_f32m1x3(a_ptr, vector_length);
vfloat32m1_t a_x = __riscv_vget_v_f32m1x3_f32m1(a_f32m1x3, 0); // all x
vfloat32m1_t a_y = __riscv_vget_v_f32m1x3_f32m1(a_f32m1x3, 1); // all y
vfloat32m1_t a_z = __riscv_vget_v_f32m1x3_f32m1(a_f32m1x3, 2); // all z

After deinterleaving, the pipeline is the same across all ISAs: compute centroids, build the 3×3 cross-covariance matrix via outer products, decompose it with a McAdams branching-free SVD using 16 fixed Jacobi iterations, and apply a reflection correction when det(R) = -1.

This is one of the few workloads where Apple’s M-cores clearly outperform Xeon4 — NEON’s vld3q is a single-instruction stride-3 deinterleave, while Skylake needs six VPERMT2PS shuffles across three registers. Through Python bindings, NumKong’s Kabsch reaches 261 M points/s — roughly 19x SciPy’s Rotation.align_vectors at 14 M points/s, and 200x BioPython’s SVDSuperimposer at 1.3 M points/s.

Ozaki Matrix Multiplication

Ozaki scheme decomposes a multiplication of wide floats into many multiplications of narrower floats, merging the results. On GPUs, the typical use is leveraging Float16 Tensor Cores for Float32 GEMMs. NumKong does something different — Float64 products via Float32 SME outer-product instructions on Apple M4.

The idea: split each Float64 value into three non-overlapping mantissa slices of 19+17+17 bits. Every slice fits within Float32’s 24-bit significand, so each pairwise product is exact in Float64 — the widest cross-product is 19+19 = 38 bits, well under 53.

1
2
3
4
5
6
7
8

nk_fui64_t bits = {.f = value};
bits.u &= 0xFFFFFFFC00000000ULL;        // mask to top 19 significant bits
nk_f64_t high = bits.f;
nk_f64_t remainder = value - high;
bits.f = remainder;
bits.u &= 0xFFFFFFF000000000ULL;        // mask to next 17 significant bits
nk_f64_t mid = bits.f;
nk_f64_t low = remainder - mid;         // remaining ≤17 bits

All cross-products where the slice indices sum to ≤ 2 must be accumulated: $A_0 B_0$, $A_0 B_1 + A_1 B_0$, $A_0 B_2 + A_1 B_1 + A_2 B_0$ — six FMOPA instructions across three ZA tile accumulators. The tile schedule is carefully ordered to minimize write-after-write pipeline stalls: ZA3, ZA2, ZA1, ZA3, ZA2, ZA3 — nine cycles instead of fifteen with naive round-robin.

The Ozaki SME path is 2.5x faster than the Dot2 NEON path while achieving sub-1 mean ULP. The serial path at 6 ULP shows what happens without compensated accumulation.

Ozaki schemes originated in the work of Ozaki, Ogita, Oishi, and Rump on accurate matrix multiplication, building on earlier error-free summation techniques. The GPU community adopted them to squeeze Float32 accuracy out of Float16 Tensor Cores — NVIDIA’s cuBLAS uses a 2-way split for TF32. SME’s outer-product tile architecture makes the cross-product scheduling particularly natural — each FMOPA is a full rank-1 update, so interleaving slices across tiles maps directly to the hardware.

Possible improvement directions for kernels: SIMD-accelerated PRNGs (#299), fused Attention kernels, trajectory matching for geospatial (#186), and a proper traditional GEMM API (#312).

Evolution of GEMMs

How Software Diverges

The convergence table above shows that every vendor agrees on what to compute — but the implementations are so different that you cannot write one kernel and compile it for both Intel and Apple.

AMX computes $C \mathrel{{+}{=}} A_{tile} \cdot B_{tile}^T$ — an inner product that consumes the entire K dimension inside a single instruction. SME computes $C \mathrel{{+}{=}} a_{col} \otimes b_{row}$ — a rank-1 outer product that streams through K one step at a time. Same goal, fundamentally different data flow:

AMX is an isolated accelerator: you configure tiles, run tile multiplies, store results, then return to AVX-512 for everything else. SME shares register state with Streaming SVE — you can interleave outer products with predicated vector arithmetic, comparisons, and reductions without leaving streaming mode. That is what makes fused GEMM+epilogue kernels like maxsim_packed and bilinear cleaner on SME than on AMX.

The boundary handling difference is equally practical. On SME, svwhilelt generates a predicate for partial tiles — the same FMOPA fires with fewer active lanes, zero code duplication. On AMX, LDTILECFG can reconfigure tile dimensions mid-kernel, but NumKong avoids the overhead by pre-packing remainder rows into a separate row-major edge region processed via AVX-512.

Despite all these differences, both AMX and SME provide extraordinary arithmetic density — thousands of multiply-accumulates per instruction, far more than any scalar or even SIMD vector path. That density is so high that it becomes worthwhile to reformulate other operations as matrix multiplications: cosine similarities become a GEMM plus a norm division, L2 distances become a GEMM plus pre-computed squared norms, retrieval scoring becomes a GEMM plus a running argmax. The cost of admission is packing your data into the hardware’s preferred layout; the payoff is accessing the fastest arithmetic the chip has.

From Pre-Packing to Epilogues

The classical BLAS contract hides this: you hand it two matrices, it repacks internally, every call. That made sense in 1979 when DGEMM was the only operation and the matrices changed between calls. But if packing is ISA-specific — VNNI interleaving, column-major tiling, edge regions, boundary predicates — and the data is queried millions of times, hiding it inside every call is wasteful.

NumKong makes packing explicit, and fuses the “what do I actually want from this GEMM” into the kernel as an epilogue. dots_packed returns raw dot products. angulars_packed fuses norm division into the tile loop — cosine similarity without a second pass over the output matrix. euclideans_packed adds pre-computed squared-norm terms to convert dots into L2 distances. maxsim_packed tracks a running argmax inside the GEMM — for ColBERT-style late interaction scoring, the argmax never materializes the full score matrix. bilinear streams through metric matrix rows, computing $a \times M \times b$ for learned distance functions.

The packing itself does far more than reordering bytes. Since GEMM is $O(N^3)$ and packing is $O(N^2)$, even expensive transforms are asymptotically free — but what those transforms do matters:

The last one deserves a moment. On a set-associative cache, consecutive rows at a power-of-2 stride all map to the same cache sets, effectively shrinking usable L1/L2 capacity to just the associativity. Adding a single element of padding — stride 257 instead of 256 — spreads rows across different sets and restores full cache utilization. It costs one wasted byte per row and saves an order of magnitude on large matrices.

What the user sees is: pack once, query many, fuse your metric. And the payoff is real — on Intel Xeon4, UInt8 Euclidean distances:

• Vector-vector: nk_euclidean_u8 — 40.8 gso/s
• Matrix-matrix: nk_euclideans_packed_u8 — 672 gso/s

That is a 16x throughput increase from reformulating pairwise distances as a tiled GEMM with a fused epilogue — same input data, same output semantics, same hardware.

Don’t Materialize What You Won’t Need

ColBERT-style late-interaction scoring is a good example of a fused epilogue in action: for each query token, find the most similar document token, then sum those max similarities. Getting per-token embeddings from HuggingFace is straightforward:

1
2
3
4
5
6
7
8

from transformers import AutoModel, AutoTokenizer

tokenizer = AutoTokenizer.from_pretrained("colbert-ir/colbertv2.0")
model = AutoModel.from_pretrained("colbert-ir/colbertv2.0")
query = model(**tokenizer("what is a dog?", return_tensors="pt")).last_hidden_state[0].detach().numpy()
doc = model(**tokenizer("a dog is a pet", return_tensors="pt")).last_hidden_state[0].detach().numpy()
assert query.shape == (7, 768)          # 7 tokens × 768-dim embeddings
assert doc.shape == (7, 768)            # 7 tokens × 768-dim embeddings

The NumPy way materializes the full score matrix — for real workloads with thousands of tokens, that’s megabytes of temporary memory:

1
2
3
4
5
6
7

import os
os.environ["OMP_NUM_THREADS"] = "1"    # single-threaded for fair comparison
import numpy as np

scores = np.empty((query.shape[0], doc.shape[0]), dtype=np.float32)
np.matmul(query, doc.T, out=scores)    # full score matrix materialized
result = scores.max(axis=1).sum()      # reduce after the fact

NumKong’s maxsim_packed never materializes that intermediate matrix — tiles flow from one register to another and are progressively reduced to a single scalar:

1
2
3
4

import numkong as nk
query_packed = nk.maxsim_pack(query.astype(nk.bfloat16))
doc_packed = nk.maxsim_pack(doc.astype(nk.bfloat16))
result = nk.maxsim_packed(query_packed, doc_packed)      # no intermediate matrix

At 2048³ on a single Xeon4 core, NumPy’s f32 → f32 path reaches 129 gso/s. NumKong’s BFloat16 path hits 428 gso/s — over 3x faster while using half the input memory for input, and 4x less memory overall. The same pattern applies to nk_bilinear — computing aᵀ × C × b without materializing the C × b intermediate vector.

The memory discipline doesn’t stop at kernels — it extends to the runtime itself.

Memory Management & Parallelism Model

No hidden allocations. No hidden threads. OpenBLAS allocates per-thread buffers via mmap behind every GEMM — leading to 14 lock/unlock pairs per small multiply, deadlocks after fork(), and silently wrong results from thread-unsafe allocation. NumKong never allocates — you own the buffer, you own the threads.

But “you own the threads” is harder than it sounds. Each thread must call nk_configure_thread before any kernel — it flushes denormals to zero on x86 to avoid 100x slowdowns on subnormal inputs, requests AMX tile permission from the Linux kernel via ARCH_REQ_XCOMP_PERM, and sets the rounding mode. Then there is the question of which threads to use. #pragma omp parallel for schedule(static) splits rows evenly — but Apple M4 has 4 performance cores and 6 efficiency cores running at different frequencies, so equal splits leave the fast cores idle waiting for the slow ones. Intel server chips have a different problem: 2-socket Xeon4 has multiple NUMA nodes with vastly different memory latencies — a thread on socket 1 reading matrix A from socket 0’s memory pays 2-3x the latency.

The efficient pattern for a large GEMM on a NUMA machine looks like this: each node gets a local copy of the small-ish packed B, works on the slice of A that lives in its local memory, and writes to the corresponding row block of C — also local. This is the problem ForkUnion is being built to solve — a work-in-progress NUMA-aware fork-join thread pool with core pinning and heterogeneous QoS awareness:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17

fu::linux_colocated_pool_t first_socket, second_socket;
first_socket.try_spawn(topology.nodes[0], cores_per_socket);    // pin to socket 0 cores
second_socket.try_spawn(topology.nodes[1], cores_per_socket);   // pin to socket 1 cores

auto init = [](auto) noexcept { nk_configure_thread(); };       // denormals, AMX, rounding
first_socket.for_threads(init);
second_socket.for_threads(init);

nk_size_t half = query_rows / 2;
first_socket.for_slices(half, [&](auto slice) noexcept {
    nk_dots_packed_bf16(queries + slice.first * depth, packed_b_first,
        columns, depth, results + slice.first * columns);
});
second_socket.for_slices(query_rows - half, [&](auto slice) noexcept {
    nk_dots_packed_bf16(queries + (half + slice.first) * depth, packed_b_second,
        columns, depth, results + (half + slice.first) * columns);
});

No mutexes, no dynamic allocation on the hot path, no CAS primitives. Each thread is pinned to a physical core, reads from NUMA-local memory, and writes to its own output rows.

Block-Scaling & Ideological Differences

For all the things NumKong tries to achieve, there are lines it does not cross. MXFP4 and NVFP4 block-scaled formats are one of them.

Block scaling couples elements through shared exponents — a group of 32 values shares one scale factor, so each element’s precision depends on its neighbors. That makes sense inside a model’s forward pass where training adapts to the structural bias. It does not make sense inside a dot product primitive where the caller expects every element to be self-contained.

NumKong’s stance: dequantize first, then process. If your data arrives in MXFP4 format, unpack to 8-bit mini-floats without block scaling before calling NumKong. The conversion cost is trivial compared to the multiply-accumulate, and you preserve the invariant that dot(a, b) treats every element independently.

Reproduce These Numbers

To get a quick taste, run a 2048³ BFloat16 batched dot product on your machine and see the throughput:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14

uv init nk-demo && cd nk-demo && uv add numkong numpy
uv run python -c "
import numpy as np, numkong as nk, time
height, width, depth = 2048, 2048, 2048
a = np.random.randn(height, depth).astype(nk.bfloat16)
b = np.random.randn(width, depth).astype(nk.bfloat16)
packed = nk.dots_pack(b)

t = time.perf_counter()
scores = nk.dots_packed(a, packed)
elapsed = time.perf_counter() - t
gsos = height * width / elapsed / 1e9
print(f'{height}x{width}x{depth} f16 GEMM: {gsos:.1f} gso/s in {elapsed:.4f}s')
"

You can try replacing the nk.bfloat16 casts with some more obscure mini-floats or jump to NumWars benchmarking suite to see how other operations compare against NumPy, SciPy, PyTorch, Rust ndarray, faer, geo, and others on the same workloads.
